SUBTYPE
TARECID
Level of data in this record
VERSION
TARCDVER
IRUF release identifier
SYSID
TASYSID
Originating system
IMS-LEVL
TAIMSLEV
IMS release level
TRANCODE
TATRAN
Code identifying this message
PSBNAME
TAPSBNAM
Program name
CUSTID1
TACUST
Customer ID (first 9 bytes)
CUSTID2
TACUST
Customer ID (last 9 bytes)
LTERM
TALGTRNM
Logical terminal
REGION
TAREGID
Processing region name
CLASS
TACLASS
Transaction input class
TRANTYPE
TATRANT
Transaction processing type
TRANCAT
TADTRCAT
Transaction category
USER-ID
TAUSERID
Security system user ID
AGN
TAAGN
Application group number
OS-CODE
TAOSCODE
Operating system code
#-TRANS
TATRNSN
Number of transactions run
R-OPTION
TARSPOPT
Response option flag
A-DATE
TAARVDT
Arrival date
A-TIME
TAARVTM
Arrival time
S-DATE
TAXSTART
Processing start date
S-TIME
TAXSTART
Processing start time
E-DATE
TAXENDTM
Processing end date
E-TIME
TAXENDTM
Processing end time
I-Q-TIME
TAINQTM
Time spent in queue
ELAPSED
TAELAPSE
Transaction elapsed time
MSG-CPU
TXMPROCP
Message region CPU time
OPEN-CPU
TXMOPNCP
Open/close CPU time
MSG-DLI
TXMDLICP
Message region DLI CPU time
CTL-DLI
TXCDLICP
Control region DLI CPU time
MSG-BUF
TXMBUFCP
Message region buffer CPU time
CTL-BUF
TXCBUFCP
Control region buffer CPU time
DB2ID
TARESSID
DB2 subsystem ID
DB2-CPU
TAXESSCP
Dependent region CPU time to process DB2 requests
DB2-TRAN
TATRNDB2
Number of transactions that accessed DB2
TRAN-CPU
TAXTCPU
Total CPU time used by the transaction
TTL-CPU
TAXZTCPU
Total dependent region application CPU time including normalized time on ZAAP or ZIIP
NO-Z-CPU
TAXZONCP
Total dependent region application CPU time excluding time on ZAAP or ZIIP
ZAAPELIG
TAXZAOCP
Total dependent region application CPU time eligible for ZAAP that ran on a standard CP
ZIIPELIG
TAXZIOCP
Total dependent region application CPU time eligible for ZIIP that ran on a standard CP
A-STORE
TACRALOC
Allocated storage
U-STORE
TACRUSED
Used storage
A-KSTRGM
TAAKCORE
Allocated KSTORAGE minutes
U-KSTRGM
TAUKCORE
Used KSTORAGE minutes
R-MSWCNT 1
TARSWCNT
Message switch count
R-MSNTCT 1
TARSENCT
Message sent count
R-MDQCNT 1
TARDEQCT
Message dequeue count
R-MSWLEVL 1
TARMSGLV
Message switching level
R-ORIGDT 1
TAXORGSW
Original arrival date
R-ORIGTM 1
TAXORGSW
Original arrival time
R-ADATE 1
TARARVDT
Message switch arrival date
R-ATIME 1
TARARVTM
Message switch arrival time
R-IDATE 1
TAXISRDT
Output message insert date
R-ITIME 1
TAXISRDT
Output message insert time
R-SDATE 1
TAXSNTDT
Output message sent date
R-STIME 1
TAXSNTDT
Output message sent time
R-DDATE 1
TAXDEQDT
Output message dequeue date
R-D-TIME 1
TAXDEQCT
Output message dequeue time
R-LINE 1
TALINE
Input line number
R-PTERM 1
TAPTERM
Input physical terminal
R-INPUTQ 1
TAXINQTM
Alternate input queue time
R-OUTPTQ 1
TAXOUTQ
Alternate output queue time
R-DE-Q 1
TAXDEQ
Alternate dequeue time
R-RESPON 1
TAXRSP
Alternate response time
R-OMSCDT
TAXORGAR
Original MSC transaction date
R-OMSCTM
TAXORGAR
Original MSC transaction time
R-DSMSCD
TAXMSCAR
MSC destination transaction arrival date
R-DSTMSCT
TAXMSCAR
MSC destination transaction arrival time
R-IQ-MSW
TAXINQ
Transaction input queue time
R-OARVLD
TAXARVDT
Transaction arrival date
R-OARVLT
TAXARVDT
Transaction arrival time
$-ASTORE
TACRACHG
Charge for allocated KSTORAGE
$-USTORE
TACRUCHG
Charge for used KSTORAGE
$-MSGCPU
TAMSPCHG
Charge for message region CPU time
$-MIN
TACDCHG
Minimum transaction charge
$-MSGDLI
TAMSDCHG
Charge for message region DL/I CPU time
$-CTLDLI
TAMSCCHG
Charge for control region DL/I CPU time
$-RESRCE
TARESCHG
Total resource charges
$-UNIT
TAUNTCHG
Transaction unit charge
$-PRORAT
TAPROCHG
Total prorated charges
$-BILABL
TABILCHG
Total charge
$-VAR
TAVARCHG
Charge variance
$DB2CPU
TAXESSCP
Charge for dependent region DB2 CPU time
SAP FLG
TASAPX
SAP exit-invoked indicator (Y or N)
U-AREA1
TAUSER
User area (first 10 bytes)
U-AREA2
TAUSER
User area (last 10 Bytes)
#-SEGS
TANOSEGS
Number of segments
SMQGRPNM
TASMQGPN
Shared message queues group name
ABENDCOD
TAABNCOD
Transaction abend code
SPRC
TASPRC
Fast Path sync point return code
BGQCT
TABGQCT
Fast Path balancing group queue count
MSG-OPN
TXMOPNCP
Dependent region open/close CPU time
RTCODE
TARC
Fast Path routing code
NBA
TANBA
Fast Path normal buffer allocation
OBA
TAOBA
Fast Path overflow buffer allocation
BUSED
TABUSED
Fast Path buffers used
NCIC
TANCIC
Number of Fast Path CI contentions
NWFB
TANWFB
Number of waits for Fast Path buffers
WFOBL
TAFLAG
Wait for Fast Path overflow buffer latch
MISC-IWT
TARW1OTH
Miscellaneous IWAIT time
SYNC-IWT
TARW2OTH
Sync miscellaneous IWAIT time
SYNLATCH
TARW2LCH
Sync latch IWAIT time
SYNCVSAM
TARW2IOV
Sync VSAM I/O IWAIT time
SYNCOSAM
TARW2IOO
Sync OSAM I/O IWAIT time
DLITMMSC
TARW3OTH
DLI/TM miscellaneous IWAIT time
DLITMLAT
TARW3LCH
DLI/TM latch IWAIT time
MISC-OC
TARW4OTH
Open/Close miscellaneous IWAIT time
DBRC-OC
TARW4DBR
Open/Close DBRC IWAIT time
I/O-OC
TARW4IO
Open/Close I/O IWAIT time
DLIDB-M
TARW5OTH
DLI/DB miscellaneous IWAIT time
DLIDB-LAT
TARW5LCH
DLI/DB latch IWAIT time
DLIDBLOC
TARW5LCK
DLI/DB lock IWAIT time
DLIDBVSM
TARW5IOV
DLI/DB VSAM IWAIT time
DLIDBOSM
TARW5IOO
DLI/DB OSAM IWAIT time
DLIDBDEDB
TARW5IOD
DLI/DB DEDB IWAIT time
APPL-ELP
TAREAPPL
Application elapsed time
DLIT-ELP
TAREDLTM
DLI/TM elapsed time
DLID-ELP
TAREDLDB
DLI/DB elapsed time
DB2-ELAP
TAREDB2
DB2 elapsed time
MQS-ELP
TAREMQS
MQS elapsed time
ESS-ELP
TAREOESS
ESS elapsed time
OPCL-ELP
TAREOPCL
Open/Close elapsed time
SYNC-ELP
TARESYNC
Sync elapsed time
1ST-DLI
TARE1STD
Schedule to first DL/I call elapsed time
DLI-LAST
TARELDLI
DL/I last call elapsed time
FLSE-ELP
TARFALST
False schedule elapse time
CPU-AFTER
TARXCPU
CPU time after transaction stop is set
CNT/PTS
TARXCKPC
Count of checkpoints and syncpoints
MAX-LOCK
TARXCKPM
Maximum number of locks held (highwater mark)
TOT-LOCK
TARXCKPT
Total number of locks held for all checkpoints
CON-DATE
TAROTCON
IMS Connect start date
CON-TIME
TAROTCON
IMS Connect start time
CON-NAME
TAROTSTC
IMS Connect jobname or started task name
PORT-ID
TAROTPRT
IMS Connect port ID
CLNTTYPE
TAROTMCL
OTMA client type
CON-IP
TAROTIP
IMS Connect client IP address
CLNT ID
TAROTCLN
IMS Connect client ID
SEC-USRID
TAROTUSR
OTMA security user ID
OTMACOR
TAROTCOR
OTMA correlator
CLNTPTID
TAROTCLP
IMS Connect client port ID
TMEMNAME
TAROTMAM
OTMA Tmember name
FALSESCHD
TARFALSC
Number of false schedules
RSE-NAME
TARRSENM
RSE name
MAP-NAME
TAROTMAP
OTMA map name
CICSAPPL
TARCAPPL
CICS application ID
SEGTYPE 1
TARPCBA
I/O PCB segment
LTERM 1
TATERMNM
Originating LTERM
LINENBR 1
TAPCLN
PCB line number
CON-TIME 1
TAPCONTM
Connect time
#-MGU 1
TAPCIOGU
Number of message get uniques
#-MGN 1
TAPCIOGN
Number of message get nexts
#-MISRT 1
TAPCIOIN
Number of message inserts
#-MPURGE 1
TAPCIOPU
Number of message purges
#-MOTHR 1
TAPCIOOT
Number of other message calls
CNT-IN 1
TAIMSGCT
Number of bytes input
IN-SPA 1
TAISPACT
Number of bytes input to SPA
IN-OTHR 1
TAIOTHCT
Number of other bytes input
CNT-OUT 1
TAOMSGCT
Number of bytes output
OUT-SPA 1
TAOSPACT
Number of bytes output from SPA
OUT-ATER 1
TAATERCT
Number of bytes output from alternate area
OUT-ATRN 1
TAATRNCT
Number of bytes output from alternate message
OUT-OTHR 1
TAOOTHCT
Number of other bytes output
$-CONECT 1
TAPCCHCC
Charge for connect time
$-MGU 1
TAPCCHGU
Charge for message get uniques
$-MGN 1
TAPCCHGN
Charge for message get nexts
$-MISRT 1
TAPCCHIN
Charge for message inserts
$-MPURGE 1
TAPCCHPU
Charge for message purges
$-MOTHR 1
TAPICHOT
Charge for other characters
$-INPUT 1
TAPCCHIC
Charge for input characters
$-IN-SPA 1
TAPCCHIS
Charge for input space characters
$-IN-OTH 1
TAPCHIOT
Charge for other input characters
$-OUTPUT 1
TAPCCHOC
Charge for output characters
$-OUTSPA 1
TAPCCHOS
Charge for output space characters
$-OUTATER 1
TAPCHTMS
Charge for alternate characters
$-O-ATRN 1
TAPCHTNC
Charge for alternate message queue characters
$-OTHER 1
TAPOCHOT
Charge for other characters
SEGTYPE 2
TASEGTPD
DBD segment
DB/DD-NM 2
TAD2DNM
D2D or DD name
Note
The IRUF trailer information is collected either at the data2ase or data set level based on the setting of the DBTNAME parameter in the IMFECPxx parameter mem2er. That is, DBTNAME=DB or DBTNAME=DD.
The D2/DD-NM field can be a DBD name or a DD name, based on the setting that was in place when the data was collected.
D2DORG 2
TADORG
DBD organization
DMB-SIZE 2
TADMBPLS
DMB pool requirements
#-GU 2
TADBIOGU
Number of get uniques
#-GN 2
TADBIOGN
Number of get nexts
#-ISRT 2
TADBIOIN
Number of inserts
#-DELETE 2
TADBIODL
Number of deletes
#-REPL 2
TADBIORP
Number of replaces
#-OTHER 2
TADBIOOT
Number of other calls
#-ISAMR 2
TADBIOIR
Number of ISAM key reads
#-ISAMW 2
TADBIOIW
Number of ISAM key writes
#-OSAMR 2
TADBIOOR
Number of OSAM nonkey reads
#-OSAMW 2
TADBIOOW
Number of OSAM nonkey writes
#-REFS 2
TADBIOCT
Number of transactions that referenced this database
#-DB2DLI 2
TADB2DLI
Number of DL/I calls made if a transaction also accesses DB2
#-NO-I 2
TADBIONI
Number of I/O inputs
#-NO-O 2
TADBIONO
Number of I/O outputs
DB-VERSN 2
TADBVERS
IMS database version number
$-GU 2
TADBCHGU
Charge for get uniques
$-GN 2
TADBCHGN
Charge for get nexts
$-ISRT 2
TADBCHIN
Charge for inserts
$-DELETE 2
TADBCHDL
Charge for deletes
$-REPL 2
TADBCHRP
Charge for replaces
$-OTHER 2
TADBCHOT
Charge for other DLI calls
$-ISAMR 2
TADBCHIR
Charge for ISAM key reads
$-ISAMW 2
TADBCHIW
Charge for ISAM key writes
$-OSAMR 2
TADBCHOR
Charge for OSAM nonkey reads
$-OSAMW 2
TADBCHOW
Charge for OSAM nonkey writes
$-NO-I 2
TADBCHNI
Charge for I/O inputs
$-NO-O 2
TADBCHNO
Charge for I/O outputs
PLANNAME 3
TAD2PLAN
DB2 plan name for transaction
#-SEL/F 3
TAD2SEL
Number of SQL select and fetch calls
#-OPENS 3
TAD2OPEN
Number of SQL open calls
#-ISRT 3
TAD2ISRT
Number of SQL insert calls
#-DELETE 3
TAD2DLET
Number of SQL delete calls
#-UPD 3
TAD2UPD
Number of SQL update calls
#-DDL 3
TAD2DDL
Number of SQL Data Definition Language calls
#-DYN 3
TAD2DYN
Number of SQL dynamic calls
#-CTRL 3
TAD2CTRL
Number of SQL control-type calls
#-OTHER 3
TAD2OTHR
Number of other SQL calls
#-REFS 3
TAD2REFS
Number of transactions that referenced DB2
$-READ 3
TAD2CHGR
Charge for number of read-type calls
$-UPDATE 3
TAD2CHGU
Charge for number of update-type calls
$-DDL 3
TAD2CHGD
Charge for number of Data Definition Language calls
$-DYN 3
TAD2CHGY
Charge for number of dynamic SQL calls
$-CTRL 3
TAD2CHGC
Charge for number of control-type calls
$-OTHER 3
TAD2CHGO
Charge for number of other DB2 calls
SEGTYPE 4
TAMSEGTY
MQ segment
The value is M.
MQ-SSID 4
TAMSSID
ID of the MQ subsytem
#-GET 4
TAMQGET
Number of GET calls
#-PUT 4
TAMQPUT
Number of PUT calls
#-PUT1 4
TAMQPUT1
Number of PUT1 calls
#-SET 4
TAMQSET
Number of SET calls
#-OPEN 4
TAMQOPEN
Number of OPEN calls
#-CLOSE 4
TAMQCLOS
Number of CLOSE calls
#-BACK 4
TAMQBACK
Number of BACK calls
#-CMT 4
TAMQCMT
Number of CMT calls
#-CONN 4
TAMQCONN
Number of CONN calls
#-DISC 4
TAMQDISC
Number of DISC calls
#-INQ 4
TAMQINQ
Number of INQ calls
#-UNKN 4
TAMQUNKN
Number of calls with an unknown type
$-GET 4
TAMQCHGG
Amount charged for GET calls
$-PUT 4
TAMQCHGP
Amount charged for PUT calls
$-PUT1 4
TAMQCHG1
Amount charged for PUT1 calls
$-SET 4
TAMQCHGS
Amount charged for SET calls
$-OPEN 4
TAMQCHGO
Amount charged for OPEN calls
$-CLOSE 4
TAMQCHGC
Amount charged for CLOSE calls
$-BACK 4
TAMQCHGB
Amount charged for BACK calls
$-CMT 4
TAMQCHGT
Amount charged for CMT calls
$-CONN 4
TAMQCHGN
Amount charged for CONN calls
$-DISC 4
TAMQCHGD
Amount charged for DISC calls
$-INQ 4
TAMQCHGI
Amount charged for INQ calls
$-UNKN 4
TAMQCHGU
Amount charged for calls of an unknown type
SEGTYPE 5
TASEGTPR
Response segment
R-TRNCAT 5
TARESCAT
Transaction category
R-RESPTM 5
TARSPTM0
Response time work area
R-RESPCNT 5
TARSPCT0
Response count work area
R-RSPTM1 5
TARSPTM1
Response threshold 1
R-RSPCT1 5
TARSPCT1
Transaction count 1
R-RSPTM2 5
TARSPTM2
Response threshold 2
R-RSPCT2 5
TARSPCT2
Transaction count 2
R-RSPTM3 5
TARSPTM3
Response threshold 3
R-RSPCT3 5
TARSPCT3
Transaction count 3
R-RSPTM4 5
TARSPTM4
Response threshold 4
R-RSPCT4 5
TARSPCT4
Transaction count 4
R-RSPTM5 5
TARSPTM5
Response threshold 5
R-RSPCT5 5
TARSPCT5
Transaction count 5
R-RSPTM6 5
TARSPTM6
Response threshold 6
R-RSPCT6 5
TARSPCT6
Transaction count 6
R-RSPTM7 5
TARSPTM7
Response threshold 7
R-RSPCT7 5
TARSPCT7
Transaction count 7
R-RSPTM8 5
TARSPTM8
Response threshold 8
R-RSPCT8 5
TARSPCT8
Transaction count 8
R-RSPTM9 5
TARSPTM9
Response threshold 9
R-RSPCT9 5
TARSPCT9
Transaction count 9
R-RSPT10 5
TARSPTMA
Response threshold 10
R-RSPC10 5
TARSPCTA
Transaction count 10
R-RSPT11 5
TARSPTMB
Response threshold 11
R-RSPC11 5
TARSPCTB
Transaction count 11
R-RSPT12 5
TARSPTMC
Response threshold 12
R-RSPC12 5
TARSPCTC
Transaction count 12
