Project variablesActionBHIP_Hom_Webhook_Action

Enter the action to create or update a webbook for BMC Helix Operations Management.

Valid values include:

  • CREATE
  • UPDATE
BHIP_Integration_API_Name_HOMEnter a name for the Webhook API to be created in the BMC Helix iPaaS API Manager for BMC Helix Operations Management.

By default, the value is set to HOMTOSNOWWEBHOOK.

BHIP_Integration_API_Name_SNOWEnter a name for the Webhook API to be created in the BMC Helix iPaaS API Manager for ServiceNow.

By default, this value is set to SNOWTOHOMWEBHOOK.

BHIP_Integration_API_Method

Enter a RestAPI method that is used by the Webhook API created for BMC Helix Operations Management and ServiceNow. This value is added to the BMC Helix iPaaSJitterbit API.

The following values are valid:

  • POST
  • GET
  • PUT
  • DELETE

The default value is POST.

Do not change the default value.

BHIP_Integration_API_Response_Type_HOM

Enter the REST API response type used by the Webhook API to handle requests from BMC Helix Operations Management.

This value is added in the BMC Helix iPaaS Jitterbit API.

The following values are valid:

  • VARIABLE
  • FINAL_TARGET

The default value is VARIABLE.

BHIP_Integration_API_Response_Type_SNOW

Enter the REST API response type used by the Webhook API to handle requests from ServiceNow.

This value is added in the BMC Helix iPaaS Jitterbit API.

The following values are valid:

  • VARIABLE
  • FINAL_TARGET

The default value is VARIABLE.

BHIP_Integration_API_Security_Profile_Type_HOMEnter a security profile type.

You can set the following values for this variable:

  • BASIC
  • ANONYMOUS

The default is BASIC.

Enter comma separated values to select multiple profile types; for example, BASIC, ANONYMOUS.

Important:

  • For profile types supported by the BMC Helix Operations Management application, the security profiles are automatically created by the integration template when you enable the integration.
  • BMC Helix iPaaS does not support OAuth authentication for this application.
BHIP_Integration_API_Security_Profile_Type_SNOW

Enter a security profile type.

You can set the following values for this variable:

  • BASIC
  • ANONYMOUS

The default value is BASIC.

Enter comma separated values to select multiple profile types; for example, BASIC, ANONYMOUS.

Important:

  • For profile types supported by the ServiceNow application, the security profiles are automatically created by the integration template when you enable the integration.
  • BMC Helix iPaaS does not support OAuth authentication for this application.
BHIP_Integration_API_Security_Profile_Name_Suffix_HOM

Enter a suffix to be added to the name of security profiles created for BMC Helix Operations Management.

BHIP_Integration_API_Security_Profile_Name_Suffix_SNOWEnter a suffix to be added to the name of security profiles created for ServiceNow.BHIP_API_TimeOut

Enter a value, in seconds, for an API timeout.

The API times out if the integration template takes more than the value you define.

The minimum value must range between 30 and 180. By default, the value is set to 60.

BHIP_API_User_Roles

Enter comma-separated values of the user roles assigned for the BMC Helix iPaaS API. Leave this value blank to restrict access only to administrators.

Only a user with these roles can access the APIs.

BHIP_Integration_API_Security_Profile_BASIC_Auth_Username

For the BASIC security profile type, enter a user name to be used to create the basic authentication security profile in BMC Helix iPaaS.

This user name is used for authentication by the Jitterbit API and the Webhook API.

BHIP_Integration_API_Security_Profile_BASIC_Auth_Password

For the BASIC security profile type, enter a password to be used to create the basic authentication security profile in BMC Helix iPaaS.

This password is used for authentication by the Jitterbit API and the Webhook API.

BHIP_Integration_API_Security_Profile_ApiKey_Name

For the APIKEY security profile type, enter a name for the API key to set on the security profile.

This value is used by the RestAPI and Webhook script for authentication.

BHIP_Webhook_Security_Profile_Type

Enter a security profile type that the Webhook uses to call the BMC Helix iPaaS Jitterbit API.

SNOW_Webhook_APIKEY

Enter the name of the ServiceNow system property to store the apikey for the BMC Helix iPaaS APIKEY authentication profile.

SNOW_Webhook_Basic_PasswordEnter a password for the ServiceNow Webhook.SNOW_Webhook_Basic_User

Enter the name of the ServiceNow system property to store the BMC Helix iPaaS basic authentication profile user name.

SNOW_Webhook_Business_Rule_Name

Enter a name for the business rule created for the ServiceNow Webhook configuration.

SNOW_Webhook_Property_Name

Enter the name of the ServiceNow system property to store the BMC Helix iPaaS integration API.

SNOW_Webhook_Script_Include_Name

Enter a name for the script include to be used to create the Webhook.
